SYSTEM
|
Transmission:
|
Up to 1000 ft. (300 M) with suitable graded index fiber optic cable |
|
Typical Bit Error Rate:
|
Better than 10-9 |
ELECTRICAL SIGNAL INPUT/OUTPUT
FOR TRANSMITTER AND RECEIVER
|
Format:
|
HDMI |
|
Connector:
|
HDMI |
|
Data Rate:
|
Up to 3.5 Gbps |
|
Input impedance:
|
120-Ohm |
|
Input Power:
|
5VDC |
|
System Wavelength:
|
850nm |
|
Optical Interface:
|
Transmitter is disabled
when fiber is removed |
|
Optical Connector:
|
SC |
|
Operating Temperature:
|
0°C to 50°C |
|
Humidity:
|
0 to 90% Non-Condensing |
|
Metal Enclosure Size:
|
2.56" X 3.56" X 1.13"
(6.5 X 9.0 X 2.9 cm) |
|
Weight:
|
0.5lb. (225 grams) Each Unit |
|
TRANSMISSION LINE INTERFACE
Operating distance is dependent upon optical fiber core diameter and the cable's optical attenuation fiber bandwidth
at given data rate. The table below indicates cables that may be used at any data rate. These cables are available
in connectorized assemblies to meet the exact configuration of your application.
S.I.Tech offers complete links including fiber optic cable, connectors, cable assemblies, and Bit-Drivers®.
UL Listed. Meets FCC requirements of Class A, Part 15 Computing Devices Standard.
Specifications subject to change without notice.
|
Model 2830 - HDMI to Fiber Optic Transmitter/Receiver
