Operation Mode:
|
10/100 Base Ethernet switch |
|
Ports:
|
3: Ports 1 & 2 - 100 Base FX
Port 3 - wire port 10/100 Base-T(x) |
|
Input/Output Interface:
|
Shielded RJ-45, ST/SC/LC/MT-RJ |
|
Transmission Distance:
|
See chart |
|
System Wavelength:
|
1300nm MM or SM |
|
Data Rate:
|
10/100 Mbps |
|
Bit Error Rate:
|
10-9 |
|
Operating Temperature:
|
-40 °C to +85 °C |
|
Weight:
|
0.60 lb (272 grams) |
|
Enclosure:
|
IP30 |
|
Power:
|
10 to 28VDC, 5 watts |
|
Size:
|
5.25" X 4.06" X 1.21"
(133 X 103 X 31 mm)
Flange mounting option
DIN RAIL option |
|
Relative Humidity:
|
10 to 90% Non condensing |
View Complete Technical Data Sheet (PDF)
Return
|
Features:
- Layer 2 switch meets IEEE 802.3
- Unmanaged 3 port (2 optical & 1 electrical) 10/100 Mbps switch
- Optical Ports 1 & 2 - Various combinations: MM/MM, MM/SM, SM/SM - 100 Base FX
- Wire Port 3 - 10 or 100 BASE- T(x) wired as MDI - X
- Optic Connector options: ST/SC/LC/MT-RJ
- Status indicators: PWR, Link/Activity, 10/100
- Switch for port 3 configuration
- Ethernet switching:
| Packet Buffer size |
64KByte frame buffer |
| Bandwith |
1Gbps memory bandwidth |
| QoS |
802.3p based priority separating incoming packets into high and low priority transmit queues |
| Address lookup |
1K MAC address lookup table with 5 minutes aging |
| Frame discard |
Discard illegal short and long frames according to 802.3u |
| 10/100Base-T(X) Flow Control |
Full duplex: 802.3x; Half duplex: back pressure |
| Auto - Negotiation |
10 BASE-T, 100BASE TX |
Ordering Information
2703-MM-MM Both optical ports multimode
2703-MM-SM One port multimode, one port single mode
2703-SM-SM Both optical ports single mode
UL Listed. Meets FCC requirements of Class A, Part 15 Computing Devices Standard.
Specifications subject to change without notice.
|
Model 2703 - Ethernet 3 Port Switch Bit-Driver®
