S.I. Tech, Inc.Model 2809 TR / 2810 REC CCTV - Fiber Optic Video System

Operation Mode: CCTV video - color or black and white
System Bandwidth: 10 Hz to 15 MHz
Transmitter Input Impedance: 75 ohms, BNC bulkhead jack
Input Voltage: 1 Volt rms
Receiver Adjustment Range: 40:1
Linearity: 1 percent typical
Output Load Impedance: 75 ohms
Operating Wavelength*: 820 nanometers (1300 nm options)
Optical Connectors: ST or SMA receptacle
Operating Temperature: 0 °C to 50 °C
Plastic Enclosure: 6" X 6.5" X 2.75"
(15.2 X 16.5 X 7 cm)
Weight: 2lbs. (1 kg)
Input Power: 110 VAC 50/60 Hz
220 Volt Version: Model 2809V TR/2810V REC
Card Version: 2379/2380 (3000 Rack)
*1300 nanometers is an option for 5 km or longer system


Specifications subject to change without notice.
