S.I. Tech, Inc.Model 2130 - USB to Serial Fiber Converter

Operation Mode: Asynchronous
Input/Output Interface: USB Type B
Transmission Line Interface: ST optical connector is standard
Transmission Distance: See distance chart
System Wavelength: 850 or 1300 nm
Data Rate: 300bps to 3.0Mbps
Operating Temperature: 0 °C to 50 °C
Weight: 0.25 lb (100 grams)
Power: Powered from USB port of a computer
Metal Enclosure: 1.75" X 3.0" X 0.625"
Features:
  • USB to Fiber Serial Interface
  • Compatible with fiber interface found on many S.I.Tech serial data links.
    RS-232: 2005, 2505, 2507, 2617
    RS-422: 2106, 2116, 2140, 2866
    RS-485: 2110, 2128
  • Data rates 300bps to 3Mbps dependent on connecting product

Note: Requires virtual COM port (VCP) drivers supplied on disk. VCP drivers map a COM port to 2130. COM port assignment is found in Windows Device Manager under the ports tab.


Meets FCC requirements of Class B, Part 15 Computing Devices Standard, USB Standard
Specifications subject to change without notice.
